HPL Compact Laminate Lockers
Wet-area lockers with 12 mm compact laminate doors and laminate carcasses — typical 300 W × 1,900 H × 450 D mm columns in 1- to 4-tier and Z configurations, with key, coin, combination or electronic locks.
- Minimum order
- One changing-room project.
- Lead time
- Confirmed per quotation.
HPL lockers replace steel in pools, gyms, spas and school changing rooms because they do not rust in humid air and survive heavy use. Typical construction uses 12 mm compact laminate doors with thinner laminate side, back and shelf panels, on adjustable legs or a plinth.
The standard column is about 300 mm wide, 1,900 mm high and 450 mm deep, grouped in banks of two to four columns; tiers range from full-height single doors to four compartments, and Z-lockers give two full-length hanging spaces in one column. Locks are chosen by operation: key, coin-return, combination, RFID/electronic.
We supply lockers flat-packed or assembled, matched in colour to cubicles and benches for complete changing-room packages.
Key specifications
| Door | 12 mm compact laminateSource: keplerhpl.com |
|---|---|
| Carcass panels (example) | Sides 8 mm; top/shelf/bottom 8 mm; back and middle 4 mmSource: keplerhpl.com |
| Standard column | 300 W × 1,900 H × 450 D mm; banks of 2–4 columnsSource: keplerhpl.com |
| Configurations | 1–4 tier and Z-style; custom sizesSource: keplerhpl.com |
| Locks | Key, coin-return, combination, electronic/RFID |
| Properties | Water, humidity and impact resistantSource: jialifucn.com |
Typical, configurable ranges compiled from published manufacturer data. Final values are confirmed per order in the quotation and supporting test documents.
Materials
Compact laminate doors and panels; stainless hinges; lock of choice.
Dimensions & formats
Standard modules above; custom heights, widths and depths on request.
Options & customisation
- Colours and number plates
- Sloping tops, plinths or legs
- Bench-integrated lockers
Applications
- Swimming pools and leisure centres
- Gyms and spas
- School and university changing rooms
- Factory and hospital staff areas
- Offices (day lockers)
Ordering information
Minimum order
One changing-room project.
Lead time
Confirmed per quotation.
Packaging
Flat-packed or assembled; assembled units cost more to ship.
Loading & shipping
Flat-packed lockers load efficiently.
Technical documentation
- Layout and elevation drawingsAvailable on request with your RFQ
- Board technical dataAvailable on request with your RFQ
- Lock specification and master-key scheduleAvailable on request with your RFQ
Frequently asked questions
Flat-packed or assembled?
Flat-packed ships far more efficiently; assembled units save site time. We quote both where useful.
Which lock should we choose?
Key or combination for staff; coin-return or electronic/RFID for public facilities. Electronic locks require the lock supplier’s documentation.
Can colours match the cubicles?
Yes, from the same board range.
